Features
◇ Various specifications to achieve conversion between different threads.
◇ Copper plated nickel material.
| How to order | ||||
| PJT -M5M -M8F ① ② ③ | ||||
| ① Series | ② Connection thread(1) | ③ Connection thread(2) | ||
| PJT | M5F - M5 Female thread M5M - M5 Male thread M8F - M8 Female thread M8M - M8 Male thread | G1F - G1/8 Female thread G1M - G1/8 Male thread G2F - G1/4 Female thread G2M - G1/4 Male thread G3F - G3/8 Female thread G3M - G3/8 Male thread | Nil - Same as connection thread(1) M5F - M5 Female thread M5M - M5 Male thread M8F - M8 Female thread M8M - M8 Male thread G1F - G1/8 Female thread G1M - G1/8 Male thread | G2F - G1/4 Female thread G2M - G1/4 Male thread G3F - G3/8 Female thread G3M - G3/8 Male thread G4F - G1/2 Female thread G4M - G1/2 Male thread |
